Mechanical Vertical Reciprocating Conveyors (VRC)
5 Year Structural Warranty
1 Year Electrical
Vertical reciprocating conveyors are designed to move goods and materials between multiple floor levels quickly and safely. Mechanical VRC lifts may be configured for C, Z, or L loading patterns between floor levels and are available in a wide variety of platform sizes and capacities. No riders are allowed. Models may be floor mounted or pit mounted. Mechanical VRC lifts are well suited to multiple level stops. Enclosures are quoted separately. Inquire about our vertical reciprocating conveyors today.
Features and Benefits
- All controllers are assembled in our UL listed panel shop
- Mechanical vertical lifts conform ASME B20.1
- Conform to VRC Guidelines – as referenced in ASME B20.1
- Motors are equipped with integral holding brakes
- All vertical conveyor lifts have double chains
- The carriages have mechanical locking brakes in case of chain failure.
SPECIFICATION TABLE CANTILEVER MECHANICAL
| Platform | Size (in.) | Low | Overall(in.) Min Platform | Travel | Carriage | Speed | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Model | Capacity | Min | Max | Ht(in.) | Height | Width | Depth | Max(ft.) | Height | (FPM) | HP |
| VCM-1 | 1,000 | 48 x 48 | 96 X 96 | 2.25 | 110+Travel | 48 | 64 | 100 | 84 | 30 | 3 |
| VCM-2 | 2,000 | 48 x 48 | 96 X 96 | 2.25 | 110+Travel | 48 | 64 | 100 | 84 | 30 | 4 |
| VCM-3 | 3,000 | 48 x 48 | 96 X 96 | 2.25 | 110+Travel | 48 | 64 | 100 | 84 | 30 | 5 |
| VCM-4 | 4,000 | 48 x 48 | 96 X 96 | 2.25 | 110+Travel | 48 | 64 | 100 | 84 | 30 | 7.5 |
| VCM-5 | 5,000 | 48 x 48 | 96 X 96 | 3.25 | 110+Travel | 48 | 64 | 100 | 84 | 30 | 7.5 |
| VCM-6 | 6,000 | 48 x 48 | 96 X 96 | 3.25 | 110+Travel | 48 | 64 | 100 | 84 | 30 | 7.5 |
SPECIFICATION TABLE STRADDLE MAST MECHANICAL
| Platform | Size (in.) | Low | Overall(in.) Min Platform | Travel | Speed | |||||
|---|---|---|---|---|---|---|---|---|---|---|
| Model | Capacity | Min | Max | Ht(in.) | Height | Width | Depth | Max(ft.) | (FPM) | HP |
| VSM-1 | 1,000 | 48 x 48 | 96 X 96 | 2.25 | TDB | 68 | 48 | 100 | 30 | 3 |
| VSM-2 | 2,000 | 48 x 48 | 96 X 96 | 2.25 | TDB | 68 | 48 | 100 | 30 | 4 |
| VSM-3 | 3,000 | 48 x 48 | 96 X 96 | 2.25 | TDB | 68 | 48 | 100 | 30 | 5 |
| VSM-4 | 4,000 | 48 x 48 | 96 X 96 | 2.25 | 108 + Travel | 68 | 48 | 100 | 30 | 7.5 |
| VSM-5 | 5,000 | 48 x 48 | 96 X 96 | 3.25 | 110 + Travel | 68 | 48 | 100 | 30 | 7.5 |
| VSM-6 | 6,000 | 48 x 48 | 96 X 96 | 3.25 | 110+ Travel | 68 | 48 | 100 | 30 | 7.5 |
